Fully Automatic Customizable Stone Wool Sandwich Panel Making Machine Easy To Operate

Fully Automatic Customizable Stone Wool Sandwich Panel Making Machine Easy To Operate

Brand Name:	Greenson
MOQ:	1
Price:	$700000-$800000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Product Name:

Customized Advanced Stone Wool Composite Sandwich Panel Making Machine

Keyword:

PU Edge-Sealed Rock Wool Sandwich Panel Production Line

Application:

Building

Color:

Customer's Requirement

OEM:

Yes

Feature:

Full-Automatic

Packaging Details:

Plastic Film

Port Of Dispatch:

Tianjin

Core Components:

PLC, Engine, Bearing, Motor, Pump

Key Selling Points:

Easy To Operate

Product Description

Customized Advanced Stone Wool Composite Sandwich Panel Making Machine

This advanced production line features a rational structure, complete functionality, and easy operation. Designed for manufacturing high-quality rock wool sandwich panels through a fully automated continuous process.

Product Applications

The stone wool sandwich panel is widely used for steel structure workshops, roofs of simple and movable houses, wall bodies, suspended ceilings of air purification rooms, and separation. Rigid polyurethane foam has been recognized as the best building thermal insulation material internationally, offering low heat conductivity and high bending resistance capacity.

This rigid polyurethane foam doesn't absorb water or decay, and it cannot be damaged by insects and mice. It has good fire resistance and a wide scope of heat resistance. With the physical properties of polyurethane PU and our unique prescription, we combine high-temperature polyurethane with coating steel panels to achieve compact forming.

Production Process

Complete automated workflow: feeding, profiling, gluing, heating, trimming, grooving, and cutting
Precision low-speed metering pump with computer-controlled frequency regulation
Accurate dosing and stepless speed adjustment capabilities

Product Capabilities

Produces various flat and corrugated sheet types
Sandwich panels: thickness 40-300 mm, width 950-1200 mm
High-strength corrugated composite boards: thickness 40-300 mm, width 950-980 mm
Compatible with color steel plates, aluminum plates, stainless steel plates, and other sheet materials

Technical Specifications

Material Type	Color steel sheet; Galvanized sheet; Aluminum sheet
Material Thickness	0.3-0.8 mm
Material Width	≤1250 Mpa
Suitable Panel Length	2000-18000 mm
Suitable Panel Width	500-1200 mm
Suitable Panel Thickness	30-250 mm (excluding corrugation height)
Production Speed	3-15 m/min (Adjustable)
Valid Length of Double Belt Conveyor	12000-42000 mm
Work Pressure on Pouring Foam	150-200 Bar
Total Power	660 kW / 300 kW
Total Dimensions	130000 × 15000 × 6000 mm (Length × Width × Height)
