Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Brand Name:	Greens
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Product Name:

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Keyword:

Rock Wool Sound Insulation Material Production Line

Voltage:

380v Or Customized

Conveying Speed:

40~120 Meters/min

Swing Belt Width:

2800mm

Swing Belt Motor:

4kw (variable Frequency Motor)

Raw Material:

Basalt,dolomite

Width:

600mm-2400mm

Highlight:

rock wool insulation sheet machine

external insulation panel machine

mineral wool board production line

Product Description

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Product Specifications

Attribute	Value
Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Keyword	Rock wool sound insulation material production line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying speed	40~120 meters/min
Swing belt width	2800mm
Swing belt motor	4kw (variable frequency motor)

Product Description

The drum-type cotton collecting machine is a comprehensive system for rock wool panel production, featuring advanced automation and efficient material handling capabilities.

Technical Specifications

Product Name: Rockwool Panel Production Line
Automatic Grade: Automatic
Voltage: 380V
Panel Thickness: 30-200mm
Felt Size: 1000mm (adjustable)
Panel Density: 30-200 Kg/m3
Applicable Industries: Manufacturing Plant, Retail, Construction works
Finished products: Rock wool board
Usage: Building Material Production

System Components

The machine consists of:

Slag and cotton separation system
Cotton collection mechanism
Screen cleaning device
Cotton lifting system
Automatic refueling and lubrication system
Automatic slag discharge device

The sturdy steel structure frame houses a bearing transmission system. The drum features a mesh plate with an installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design 0
