380V Rock Wool Production Line with 40~120 meters/min Conveying Speed and 600mm-2400mm Width for Mineral Wool Board

380V Rock Wool Production Line with 40~120 meters/min Conveying Speed and 600mm-2400mm Width for Mineral Wool Board

Brand Name:	Greens
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Product Name:

Rock Wool Insulation Sheet Making Machine External Insulation Panel For Architectural Design

Keyword:

Rock Wool Sound Insulation Material Production Line

Voltage:

380v Or Customized

Conveying Speed:

40~120 Meters/min

Swing Belt Width:

2800mm

Swing Belt Motor:

4kw (variable Frequency Motor)

Raw Material:

Basalt,dolomite

Width:

600mm-2400mm

Highlight:

rock wool insulation sheet machine

external insulation panel machine

mineral wool board production line

Product Description

Rock Wool Insulation Sheet Making Machine

Advanced external insulation panel production system for architectural design applications

Product Overview

The drum-type cotton collecting machine is a comprehensive system for rock wool panel production, featuring advanced automation and efficient material handling capabilities.

Technical Specifications

Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Keyword	Rock wool sound insulation material production line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying Speed	40~120 meters/min
Swing Belt Width	2800mm
Swing Belt Motor	4kw (variable frequency motor)
Panel Thickness	30-200mm
Felt Size	1000mm (adjustable)
Panel Density	30-200 Kg/m³
Applicable Industries	Manufacturing Plant, Retail, Construction works
Finished Products	Rock wool board
Usage	Building Material Production
Automatic Grade	Automatic

System Components

Slag and cotton separation system
Cotton collection mechanism
Screen cleaning device
Cotton lifting system
Automatic refueling and lubrication system
Automatic slag discharge device

Operating Principle

The sturdy steel structure frame houses a bearing transmission system. The drum features a mesh plate with an installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
