Mineral Wool Production Line with 10000-50000tons/year Capacity 50-200mm Thickness and 100-200kg/m3 Density

Mineral Wool Production Line with 10000-50000tons/year Capacity 50-200mm Thickness and 100-200kg/m3 Density

Brand Name:	Greenson
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Product Name:

Building Materials Production Machine Mineral Stone Wool Production Line Manufacturer

Keyword:

Stone Wool Production Line

Production Capacity:

10000-50000tons/year

Thickness:

50-200mm

Density:

100-200kg/m3

Main Process:

Mixing, Forming, Water Cutting, Drying

Fire Resistance:

Class A1

Length:

1200-2400mm

Width:

600-1200mm

After-Sales Service:

Engineers Available To Service Machinery Overseas

Highlight:

10000-50000tons/year Mineral Wool Production Line

50-200mm Thickness Rock Wool Production Line

100-200kg/m3 Density Stone Wool Production Line

Product Description

Building Materials Production Machine Mineral Stone Wool Production Line Manufacturer

The raw materials used in rock wool production include basalt, dolomite, binders, etc. The raw materials are loaded into the hopper by the elevator, and the melting furnace is heated and melted into the melt flow tank. The lava flow is cooled and spun into fibers by the centrifuge, and then sprayed into the fiber molding room. The binder is added during the spraying process, and the fibers are heated by the negative pressure wind. Pull down to the mesh belt to form the original felt.

The mesh belt transports the original felt to the pendulum cloth machine to swing the cloth. The original felt after the swing cloth is transported to the curing furnace by the cloth machine, and runs forward between the upper and lower chain belts. The hot air blower blows the hot air into the curing furnace. The cotton felt in the furnace is solidified, and the solidified products are cut, first longitudinally cutting, and then transversely cutting, and the finished product is packaged and put into storage.

Product Parameters

Specification	Details
Application	Manufacture Rock Wool Blanket, Rock Wool Board
Capacity	10000tons/year, 20000tons/year, 30000tons/year, 40000tons/year, 50000tons/year, 60000tons/year, 70000tons/year, 80000tons/year
Raw materials	Basalt, dolomite, binders and so on
Main energy supply system	Raw coal energy supply system Power energy supply system Natural gas energy supply system
