Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Name: Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width
Brand: Hebei Greens Building Material Technology Development Co.,Ltd
SKU: Rock Wool Wall Panels Making Machine
Price: 3,000,000.00 USD
Availability: InStock

Brand Name:	Greens
Model Number:	Rock Wool Wall Panels Making Machine
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Product Name:

Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine

Keyword:

Rock Wool Building Wall Interlayer Internal Insulation Wall Rock Wool Production Line

Voltage:

380v Or Customized

Conveying Speed:

40~120 Meters/min

Swing Belt Width:

2800mm

Swing Belt Motor:

4kw (variable Frequency Motor)

Panel Thickness:

20-250mm

Panel Density:

30-250 Kg/m³

Highlight:

fireproof rock wool wall panels machine

heat preservation mineral wool production line

sound insulation rock wool board maker

Product Description

Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine

This advanced production line combines fireproofing, heat preservation, and sound insulation capabilities for manufacturing high-quality rock wool wall panels with automated efficiency.

Key Specifications

Attribute	Value
Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying speed	40~120 meters/min
Swing belt width	2800mm
Swing belt motor	4kw (variable frequency motor)

Technical Specifications

Product Name: Rockwool Panel Production Line
Automatic Grade: Automatic
Voltage: 380V
Panel Thickness: 30-200mm
Felt Size: 1000mm (adjustable)
Panel Density: 30-200 Kg/m3
Applicable Industries: Manufacturing Plant, Retail, Construction works
Finished products: Rock wool board
Usage: Building Material Production

System Components

Slag and cotton separation system
Cotton collection mechanism
Screen cleaning device
Cotton lifting system
Automatic refueling and lubrication system
Automatic slag discharge device

The machine features a sturdy steel structure frame with bearing transmission system. The drum includes a mesh plate with installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
