Small business opportunity suspended ceiling tiles perforation machine Perforated Gypsum Drywall Board Ceiling Machine

Small business opportunity suspended ceiling tiles perforation machine Perforated Gypsum Drywall Board Ceiling Machine

Brand Name:	LVJOE
Model Number:	LV-CK01
MOQ:	1 set
Price:	US $20000-80000
Payment Terms:	L/C,T/T
Supply Ability:	50 sets per year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO CE

Product Name:

Small Business Opportunity Suspended Ceiling Tiles Perforation Machine Perforated Gypsum Drywall Board Ceiling Machine

Keyword:

Small Business Opportunity Suspended Ceiling Tiles Perforation Machine Perforated Gypsum Drywall Board Ceiling Machine

Usage:

Gypsum Board, MDF, HPL, Fiber Cement Board Perforation

Width Of Perforation:

1220mm

Speed:

50 Times/minute

Overall Size:

2300*1500*2300(H*L*W)

Hole Shape:

Long Square Hole, Square Hole, Round Hole,triangle Hole, Hexagonal Hole, The Plum Blossom Hole,ichthyosisthe Hole,scale Hole And Other Different Kinds Of Hole

Punching Pressure:

160KG

Certification:

ISO9001, CE

Packaging Details:

PE film wrapped

Supply Ability:

50 sets per year

Highlight:

small business ceiling tile machine

perforated gypsum board machine

drywall ceiling perforation equipment

Product Description

Small Business Opportunity Suspended Ceiling Tiles Perforation Machine

Product Specifications

Attribute	Value
Product Name	Small business opportunity suspended ceiling tiles perforation machine Perforated Gypsum Drywall Board Ceiling Machine
Usage	Gypsum Board, MDF, HPL, Fiber cement board perforation
Width of perforation	1220mm
Speed	50 times/minute
Overall Size	230015002300(HLW)
Hole shape	Long square hole, square hole, round hole, triangle hole, hexagonal hole, plum blossom hole, ichthyosis hole, scale hole and other different kinds of holes
Punching pressure	160KG
Certification	ISO9001, CE

Plaster Board Gypsum Board Cement Board Holes Punching Line Holes Making Machine

Technical Specifications

Punching pressure: 200 ton
Stroke: 30 mm
Max mold height closed: 260mm
Number of strokes: 50 times/minute
Slide surface: 210*1100mm
Working table: 300*1670mm
Spacing of both pole: 1350mm (load the max board width 1220mm)
Power of main motor: 22kw
Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
Feeding accuracy: ±1mm
Maximum feeding rate: 100mm
Maximum feeding thickness: 20mm
Gross weight of machine: 11000kg
Overall dimension: 2300*1500*2300(H*L*W)
Structure: Welded with Q235 steel plate, H type gantry structure
Configuration: Servo motor controlled feeding device

Applications

This perforation machine is used to perforate holes in gypsum ceiling board, MgO board, MDF, HDF, Fiber cement board, and metal sheets.

Perforation Patterns

Perforating mold designs are customized. Our company maintains a punching pattern database to provide technical support for customers, including:

Round hole
Square hole
Oval hole
Round/oval cross
Hexagonal hole
Irregular hole
