Automatic Rock Wool Production Line for Building Materials

Automatic Rock Wool Production Line for Building Materials

Brand Name:	Greens
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Product Name:

China Manufacturers Direct Sales Of Rock Wool Production Line Production Machinery

Keyword:

Rock Basalt Mineral Wool Production Line

Voltage:

380v Or Customized

Condition:

New

Automatic Grade:

Automatic

Utility Requirements:

Natural Gas\Water\electricity

Felt Size:

1000mm (adjustable)

Line Speeds:

2-40 M/min

Highlight:

automatic rock wool production line

building materials rock wool machine

mineral wool board manufacturing equipment

Product Description

China Manufacturers Direct Sales Of Rock Wool Production Line Production Machinery

Product Attributes

Attribute	Value
Product Name	China Manufacturers Direct Sales Of Rock Wool Production Line Production Machinery
Keyword	rock basalt mineral wool production line
Voltage	380v Or Customized
Condition	New
Automatic Grade	Automatic
Utility requirements	natural gas\Water\electricity
Felt Size	1000mm (adjustable)
Line speeds	2-40 m/min

Production Process Overview

Our rock wool production line utilizes an electric furnace to melt raw materials including basalt, blast furnace hard slag, and dolomite. The process begins with dried materials being stored in silos, then automatically weighed and fed into the furnace through a precise charging system.

The molten material flows through a guided channel into a high-speed four-roller centrifuge, where it undergoes fibrillation under combined centrifugal force and high-speed airflow. The resulting fibers are collected on a conveyor belt to form primary felt, which is then processed through our advanced pendulum machine.

Finishing Process

Before entering the curing furnace, the secondary felt undergoes compression via our pleating and pressurizing machines to enhance strength. The complete finishing process includes:

Curing in specialized furnace
Cooling system
Precision longitudinal cutting
Online cutting system
Edge trimming
Thickness sawing
Cross-cutting
Guillotine finishing

Product Specifications

Specification	Details
Product Name	Rockwool Panel Production Line
Automatic Grade	Automatic
Voltage	380V
Panel Thickness	30-200mm
Felt Size	1000mm (adjustable)
Panel Density	30-200 Kg/m3
Applicable Industries	Manufacturing Plant, Retail, Construction works
Finished products	rock wool board
Usage	Building Material Production
