Automatic Gypsum Ceiling Panel Manufacturing Machine for PVC Lamination

Name: Automatic Gypsum Ceiling Panel Manufacturing Machine for PVC Lamination
Brand: Hebei Greens Building Material Technology Development Co.,Ltd
SKU: Automatic PVC Veneer Plaster Ceiling Machine
Price: 110,000.00 USD
Availability: InStock

Brand Name:	Greenson
Model Number:	Automatic PVC Veneer Plaster Ceiling Machine
MOQ:	1
Price:	$20000-200000
Payment Terms:	L/C,T/T
Supply Ability:	6 sets/year

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Certification:

CE ISO

Product Name:

Gypsum Plaster Ceiling Panel Board Manufacturing Machines For Pvc Gypsum Ceiling Panel

Keyword:

PVC Laminate Ceiling Tile Manufacturing Plant PVC Laminated Ceiling Tile Making Machine

Board Sheet Material:

Gypsum Board, PVC Foam Board,sectional Board, Etc

Laminating Speed:

15m/min

Stacking Mode:

10 Layers(4 Packages/layer)

Film Material:

PVC Film, Aluminum Foils, Decorative Paper, Etc.

Brand Name:

Greenson

Type:

Automatic Or Semi-automatic

Supply Ability:

6 sets/year

Highlight:

automatic gypsum ceiling panel machine

PVC lamination ceiling panel machine

fully automatic lamination manufacturing machine

Product Description

Gypsum Plaster Ceiling Panel Board Manufacturing Machines

Product Specifications

Attribute	Value
Product Name	Gypsum Plaster Ceiling Panel Board Manufacturing Machines For PVC Gypsum Ceiling Panel
Board Sheet Material	Gypsum board, PVC foam board, sectional board
Laminating Speed	15m/min
Stacking Mode	10 layers (4 packages/layer)
Film Material	PVC film, aluminum foils, decorative paper
Brand Name	Greenson
Type	Automatic or Semi-automatic

Product Description

Our plasterboard laminating machine processes paper-faced gypsum boards (6mm to 8mm thickness) by applying special glue on both sides and laminating with PVC film and PET foil. The finished boards are cut to 60x60mm size for use as false ceilings in interior decoration applications.

Key Features

Multiple automation levels available
Siemens PLC control system for reliable operation
Annual production capacity: 2-6 million square meters
Compatible materials: Gypsum board, PVC film, Aluminum foil, glue
Maximum laminating width: 1300mm
Sheet thickness range: 5-30mm
Frequency conversion synchronous speed regulation
Certifications: ISO9001, CE

Advanced Automation

Our system features simultaneous PVC film and PET foil lamination, automatic film/foil cutting, side taping, shrinking, and packing - all controlled by a PLC automation system.

Key Advantages

• Wide variety of patterns with unique visual effects

• All-dry operation enables simple, fast installation without secondary decoration

• Easy maintenance and cleaning with environmentally friendly materials

Ideal for ceiling and partition wall applications, particularly in environments requiring high cleanliness standards.
