50-200mm Mineral Rock Wool Production Line Rock Mineral Basalt Wool Production Line

50-200mm Mineral Rock Wool Production Line Rock Mineral Basalt Wool Production Line

Brand Name:	Greenson
MOQ:	1
Price:	US $2000000-4000000
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

HEBEI

Product Name:

Mineral Rock Wool Production Line Rock Mineral Basalt Wool Production Line

Keyword:

Stone Wool Production Line Rock Wool Board Production Line Mineral Wool Production Plant

Production Capacity:

10000-50000tons/year

Thickness:

50-200mm

Density:

100-200kg/m3

Main Process:

Mixing, Forming, Water Cutting, Drying

Fire Resistance:

Class A1

Length:

1200-2400mm

Width:

600-1200mm

After-Sales Service:

Engineers Available To Service Machinery Overseas

Highlight:

Mineral Rock Wool Production Line

Rock Mineral Basalt Wool Production Line

50-200mm Mineral Wool Sandwich Panel Line

Product Description

Mineral Rock Wool Production Line Rock Mineral Basalt Wool Production Line

The raw materials used in rock wool production include basalt, dolomite, binders, etc. The raw materials are loaded into the hopper by the elevator, and the melting furnace is heated and melted into the melt flow tank. The lava flow is cooled and spun into fibers by the centrifuge, and then sprayed into the fiber molding room. The binder is added during the spraying process, and the fibers are heated by the negative pressure wind. Pull down to the mesh belt to form the original felt. The mesh belt transports the original felt to the pendulum cloth machine to swing the cloth. The original felt after the swing cloth is transported to the curing furnace by the cloth machine, and runs forward between the upper and lower chain belts. The hot air blower blows the hot air into the curing furnace. The cotton felt in the furnace is solidified, and the solidified products are cut, first longitudinally cutting, and then transversely cutting, and the finished product is packaged and put into storage.

Product Parameters

Specification of SUNTHERM Rock Wool Production Line
Application	Manufacture Rock Wool Blanket, Rock Wool Board
Capacity	10000tons/year, 20000tons/year, 30000tons/year, 40000tons/year, 50000tons/year, 60000tons/year, 70000tons/year, 80000tons/year
Raw materials	Basalt, dolomite,binders and so on
Main energy supply system: (1) Raw coal energy supply system (2) Power energy supply system (3) Natural gas energy supply system
