Exterior And Interior Calcium Silicate Board Production Line Good Efficiency

Exterior And Interior Calcium Silicate Board Production Line Good Efficiency

    • Exterior And Interior Calcium Silicate Board Production Line Good Efficiency
    • Exterior And Interior Calcium Silicate Board Production Line Good Efficiency
    • Exterior And Interior Calcium Silicate Board Production Line Good Efficiency
    • Exterior And Interior Calcium Silicate Board Production Line Good Efficiency
  • Exterior And Interior Calcium Silicate Board Production Line Good Efficiency

    Product Details:

    Place of Origin: Hebei, China (Mainland)
    Brand Name: LVJOE
    Certification: CE ISO9001
    Model Number: GSLV-01

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 Line
    Price: Negotiation
    Packaging Details: Standard package for export or as per request
    Delivery Time: Within 3 months
    Payment Terms: L/C, T/T
    Supply Ability: 20 Set/Sets per Year
    Contact Now
    Detailed Product Description
    Power(W): Depends On Actual Requirement Voltage: 380V
    Annual Capacity: 2-8 Million Sqm Warranty: 1year
    Application: Calcium Silicate Board Making Main Processes: Pulping, Forming, Steaming, Drying

    Fast Delivery Exterior And Interior Calcium Silicate Board Production Line



    Product Description

    Calcium Silicate Board is composed of siliceous material(main component is SiO2)and Calcareous materials

    (main component is CaO),and adding appropriate reinforced material,processed by pulping,molding,autoclaved

    curing and drying,sanding etcs procedure to be one kind of new mtaerials with features of light weight,high

    strength,excellent refractory and heat insulation performance.



    Technical Information for Calcium Silicate board

    Calcium silicate board calculates according to 5mm thickness,annual capacity is

    5 million sqm(300 days, 3 shifts/day)

    Products variety and specification:Length*Width*Thickness=1220×(4~30)mm

    Products technical performance:

    1 Density: 0.7~1.2g/cm3

    2 Bending strength: ≥9Mpa

    3 Screw pullout force:≥75N/mm

    4 Heat conductivity coefficient: 0.29W/mk

    5 Water content: ≤10%

    6 Hot-shrinkage rate: ≤1%(600℃×3h)

    7 Noninflammability: A class

    According to customer’s requirement,ultralight(0.50~0.69g/cm3)and high

    temperature resistance (1100℃)and special specification are available.



    Item



    Unit



    Calcium Silicate Board

    Density g/cm3 <1.2
    Anti-bend strength MPa >9
    Heat conduction modulus w/m.k <0.29
    Anti-impact strength kJ/mm2 >2.0
    Pull force of screw N/mm >75
    Dry shrinkage rate % <0.2
    Non-burn performance   In accordance with standard GB8624 First ClassNon-burn Material



    The usage of Calcium Silicate board

    widely applied in the suspended ceiling system of business building, entertainment facility, supermarket, hotel,

    restaurant, hospital, theater, warehouse, apartment building and so on.



    Our Services

    1) The machine guarantee1 years except the easy worn parts such as bearings,

    electric buttons.

    2) Our company could dispatch professional engineer to buyer’s factory when the machine arrive at the

    destination.

    3)Our engineers will train the buyers' worker to operate the machine and after

    you master the machine then pay us the installation and commissioning payment.

    4) In order to ensure the machine working well, each year we will send engineer

    to check and develop the technology.
