|Place of Origin:||Hebei, China (Mainland)|
|Minimum Order Quantity:||1 Line|
|Packaging Details:||Standard package for export or as per request|
|Delivery Time:||Within 3 months|
|Payment Terms:||L/C, T/T|
|Supply Ability:||20 Set/Sets per Year|
|Main Processes:||Pulping, Forming, Steaming, Dryin||Annual Capacity:||2-8 Million Sqm|
|Power(W):||Depends On Actual Requirement||Warranty:||1year|
|Voltage:||380V||Application:||Calcium Silicate Board Making|
House Design 3 Million Output Fiber Cement Board Production Line
fiber cement board machine (silicon-calcium board for short),with main constitution of silicon and calcium,is
a new type processed step by slurry-making,moulding, braising,drying,gritting and machining Aferwards.with
advantage of light weight,high strength,fire-proof,heat insulation and easy machining,it with wide source can be
widely applied to fire-proof,separated board,hoisting board,air passage,shipping insulated board and fire-proof
door,etc.Silicon can be applied for quartz grit,diatomite,powdered coal,soil and porcelain clay,etc.while calcium
can be applied for caustic lime,plaster stone,slack lime and calcium carbide slob,etc.Strengthening material
can be used by glass fibre,mica,fibrin,organic composing fibre and mineral fibre.
Fiber cement board technical parameter:
Standard Fiber Reinforced Calcium Silicate Board
|Heat conduction modulus||w/m.k||<0.29|
|Pull force of screw||N/mm||>75|
|Dry shrinkage rate||%||<0.2|
|Non-burn performance||In accordance with standard GB8624 First ClassNon-burn Material|
Output:2-8 million Sq.m/year
Quality: In conformity with National Industrial Standard: JC/T 412.1-2006
and JC/T 412.2-2006
Fuel:natural gas, coal, heavy oil, or diesel;
Main material: sand, cement, paper fiber, glass fiber; or similar materials.
Stanard size: length: 2400-2440mm
The usage of fiber cement board:
widely applied in the suspended ceiling system of business building, entertainment facility, supermarket, hotel,
restaurant, hospital, theater, warehouse, apartment building and so on.
1) The machine guarantee1 years except the easy worn parts such as bearings,
2) Our company could dispatch professional engineer to buyer’s factory when the machine arrive at the
3)Our engineers will train the buyers' worker to operate the machine and after
you master the machine then pay us the installation and commissioning payment.
4) In order to ensure the machine working well, each year we will send engineer
to check and develop the technology.
Our company is an important supplier of fiber cement board produciton line. We have professional team and rich
experience in this field. We also have our own factory so we can give you our best price. We would like to establish
business relations with you on the basis of mutual benefits and equality. Please contact us if you are interested in
the equipment provided by our company.
