Place of Origin: | Hebei China |
Brand Name: | GREENS |
Certification: | ISO CE |
Model Number: | KM |
Minimum Order Quantity: | 1 line |
---|---|
Price: | Negotiation |
Packaging Details: | Standard package for export or as per requirement |
Delivery Time: | 2 months |
Supply Ability: | 5 lines per year |
Features: | Light Weight, High Density, High Strength, Fiber Strength | Color: | Choose |
---|---|---|---|
Fuel: | Coal, Gas, Heavy Oil, Light Oil, Diesel | Advantages: | High Efficent |
Characters: | Fireproof, Heat Insulation, Waterproof, Mould Proof, Etc | Place Of Origin: | Hebei Province |
China Manufacturer Drywall Mineral Wool Board Production Line
Overview of production process
Raw material mixing
Raw material includes granulated wool, starch and so on, all the material and additive will form the slurry with certain concentration by conveying, mixing and stir. The slurry will be pumped into high level tank and fed to net in the shape of overflow type.
Fourdrinier
Fourdrinier is made up of mesh belt, compression roller, vacuum box and transmission mechanism. After natural dehydrating, vacuum dehydrating and compression dehydrating, wet slurry will form wet slab with a certain moisture content and thickness.
water cutting device
Wet slab will cut into the board with certain length and width, and the transverse cutting is at a certain angle with the long net machine. According to procedure, length cutting.
accelerating conveyor device
After boards with certain length and width forming, they will be sent to accelerating conveyor. Through multi-stage acceleration, the distance between the wet sheet and next is gradually pulled to facilitate the distribution of the wet sheet into the kiln.
distributive bridge
Bridge kiln equipment includes bridge type distributor and plate feeding machine. The bridge type distributor is a multi-stage double roller conveyor, which is electrically operated and control wet plate of every layer be distributed into the kiln separately. Wet plates were fed into each roller of the feeder.
Plate feeding machine
The roller table of the feeder and the distributor receive the original plate containing water at the same speed, and are converted into slow speeds (ie, kiln speeds) respectively, and the wet plates are sent to the drying kiln for continuous drying.
Drying kiln
This system is the core of the whole production line, which effect directly the quality of products and energy consumption of system. There are various adjustment and control mechanism in drying kiln to ensure uniform temperature and airflow in every part, which will ensure drying quality and low consumption.
