| Place of Origin: | Hebei China |
| Brand Name: | GREENS |
| Certification: | ISO CE |
| Model Number: | FM |
| Minimum Order Quantity: | 1 Line |
|---|---|
| Price: | Negotiation |
| Packaging Details: | 1) Standards export packing which fit for long time delivery 2) Seaworthy packing.Use 20GP,40GP and 40HQ containers and frame containers |
| Delivery Time: | one month |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 20 lines per year |
| Features: | Easy To Operate | Product Name: | Machine Gypsum Board Cutting Machine |
|---|---|---|---|
| Warranty: | 1 Year | Application: | Machinery Production |
| Certification: | ISO CE | Raw Material: | Pvc Film Gypsum Board Pet Film |
1.Capacity:
7000-20000m2 per day
(basis of calculation: L:595mm, T:7mm, W:595mm, weight: 5.5 kg/M2, for 7mm board)
2.Automation
simple and high degree automatic
3.Main materials
Gypsum board , PVC film, aluminum foil, glue for PVC, glue for aluminum
4.Dimension of product
Length*Width:595*595mm,600*600mm,603*603mm,1200*600mm
Thickness:7.0mm, 7.5mm, 8.0mm,8.5mm 9.0mm
lamination machine technical parameters:
| Model | LV--1300SFM01 LV--1300SFM02 LV--1300SFM03 |
| Max. laminating width | 1300mm |
| Thickness of sheet | 5----30mm |
| Max. Laminating Speed | 15m/min |
| Speed Regulation | Frequency conversion synchronous speed regulating |
1. gypsum ceiling board lamination machine line:
gypsum board lamination machine is to laminate film on gypsum board
lamination width: 1220mm
gypsum board size: 1220*2440mm
glue: specific glue for pvc film and aluminum foil
max sheet speed: 2/15m/min
thickness of sheet: 2-50mm
motor power: 4.5kw coating and lamination part are driven by chain wheel.
2. Automatic feeding machine
1. push-type 2. suction-type Two types for choice
Cylinder push, photoelectric control, Max.Cylinder range 700mm. Through the push board platform rubber roller rolling transmission to accelerate speed,with the feature of low cost,economic and affordable (comparing to the suction type),easy to operate,fully automatic feeding.
3. Automatic cutting machine
This machine is used for cutting the laminated gypsum boards to a size of board according to saw gauge standard. First, put board to delivery roll, then come to the cutting system for the first time, and it turns to cutting system for the second time though delivery roll, then come to the board. It can be made a set of pulsed sack-duster for requirements.
4. Automatic sealing machine
right angle type gypsum board sealing machine
This machine is a gypsum board ceiling decoration edging equipment, PLC photoelectric automatic control, high speed, high capacity. Edging tight and firm. Less investment in equipment and quick. It is a board(plasterboard), Hemming preferred equipment.
5. Automatic shrinking machine
Heat shrinking machine doing the heats shrinkable packaging for gypsum board after the
completion of the sealing and cutting edge, using infrared ray heating for the film contraction.
